| Category | Descriptions | |
| Model | No. | BOX-200 |
|
Basic |
CPU | Onboard J4125/J6412 4Core 2.00-2.70GHz CPU |
| Chipset | Bay Trail D/I/M SOC integrated chipset | |
| BIOS | AMI 64Mbit Flash ROM | |
| RAM | 1×SODIMM DDR4 RAM Slot, max. 16GB | |
| Storage | 1*mSATA slot,
Msata 128/256/512GB |
|
| Graphic | Integrated UHD Graphics 600, support 4K (3840×2160px) display | |
| Network | 2*Ethernet Controller Realtek 8111F 1000M LAN | |
| Audio | Realtek ALC892 | |
| I/O | Lan | 2*RJ45 (Gigabit Ethernet) |
| USB | 2*USB2.0, 2*USB3.0 | |
| Display | 1*HD-MI, | |
| WIFI | 1*WiFi module with 2 antennas(Optional) | |
| COM | 2*COM(RS232) | |
| Button | 1*Power Button | |
| Line-out | 1*Audio-out | |
| SIM | 1*SIM Card socket(support 3G/4G module) | |
| Expansion | 1*mini-PCIe(support WiFi) | |
| OS | Operating System | Win7/8/10, Lin-ux |
| Structure | Dissipation | Fanless luminum alloy case for quick heat dissipation |
| Housing | aluminum alloy | |
| Bracket | VESA bracket | |
| Dimensions | 160.0*126.0*36.0 mm / 6.3*5.0*1.4 inch (WxDxH) | |
| Weight | 0.6KG(N.W.) | |
| Power | DC In | DC 12V |
| Temperature
& Humidity |
Working Temp. | -20°C~ 65°C (-4°F~149°F) |
| Storage Temp. | -40°C~ 80°C (-40°F~176°F) | |
| Working Humidity | 10% – 95% @40°C non-condensing | |
| Environment | Safety | CE,FCC,RoHS |
| Package | Items | pc, power adapter, Power cord, CD Driver, VESA Bracket & 2 Antennas(Optional) |
